Heavy-duty Scrap Metal Shear

TCM-HDS series heavy duty shears are specially designed for baling scrap steel, waste car body and other metal structure, non-ferrous metal (stainless steel, copper aluminum alloy, etc.), construction bar, also shearing after compressed.

  • Series:HDS
  • Payment:T/T
  • Port:ShangHai
Click To Inquire
  • Details
  • Application
  • Parameter

Details

TCM-HDS series heavy duty shear is suitable for cutting or baling scrap steel; scrap car and other metal structural parts, all kinds of non-ferrous metals, just like stainless steel, aluminum, copper and so on. Or compression packaging of these wastes directly.

Features of TCM-HDS series heavy duty shear

(1)Heavy shearing machine covers two ways of packing, compressing and shearing, multipurpose for customers.

(2)HDS heavy shearing machine has big material opening entrance, the whole scrap automobile can be put into the material box at once. It is suitable for processing some big volume light foam material or irregular shape cable, and so on.

(3)Automated operation, output 10--15 tons per hour, high production efficiency

Parameter

Model Motor(Kw*Number) Oil Pump Knife Size(mm) Chamber Size(mm)
HDS3150 30*2 160YCY*2 1400 6000*1400
HDS4000 37*2 160A7V8*2 1400 6000*1400
HDS5000 37*3/2 160A7V8*3 1600 6000*1600
HDS6300 37*5/4 160A7V8*5/4 1800 6000*1800
HDS8000 37*5 160A7V8*6/5 2000 8000*2000
